General Specifications
Full of functionality and packed inside an ergonomic design. Boasting an IP68 degree of protection, a high-resolution color display, an output rating of up to 3 W, clear digital voice quality, a man-down function and GPS localization, the PT580H Plus handheld radio offers you unbeatable TETRA communication in every situation.
-
- Operating mode
- Trunked radio mode (TMO): Communication via the TETRA radio network (semi-duplex and duplex mode)
- Direct mode (DMO): Direct communication between the radios (semi-duplex)
- Operation as ETSI type 1A DMO repeater
- Group calls
- Group call with defined priority (incl. pre-emptive priority)
- Dynamic Group Number Assignment (DGNA)
- Broadcast call (group, TMO)
- Talking party indication (TPI)
- Late Entry
- Open group call
- Group scan with priorities
- Individual call
- Individual call, half-duplex
- Individual call, duplex (TMO)
- Individual call with defined priority (also pre-emptive priority)
- Calling Line Identification Presentation (CLIP)
- Emergency call
- Emergency call to selected or pre-defined group
- Emergency call as individual call and as call to a telephone network (PSTN/PABX)
- Emergency call microphone & cyclic change of permission to talk during the emergency call
- Silent alarm (TMO)
- Calls to telephone networks (PSTN/PABX) (TMO)
- PSTN/PABX individual call, full-duplex
- PSTN/PABX individual call, half-duplex
- DTMF
- Calling Line Identification Presentation (CLIP)
- Additional call services
- Callout
- Gateway call (DMO) / repeater call (DMO)
- Security services
- Authentication (by system and mutual)
- Air interface encryption (TEA1, TEA2*, TEA3, TEA4)
- End-to-end encryption (E2EE)
- Via software (AES128 / AES256)
- Via SIM card
- Encryption of voice and SDS
- Access control with PIN /PUK code
- TETRA security class 1, 2, 3:
- Non-encrypted
- Static encryption (SCK)
- Dynamic encryption (CCK/DCK)
- Key distribution via air interface (OTAR)
- Static encryption in the DMO mode (SCK)
- Attachment/deactivation via air interface (Enable/Disable)
- Ambiance listening
- Security functions for the user
- Emergency call button
- Lone worker function / man-down alarm
- Position alarm
- Silent alarm
- Call barring
- Programmable key lock (individual keys can be excluded from the lock)
- Configuration protection / configuration password
- TX Inhibit (TXI)
- Functions of the user interface
- 20 programmable keys for direct access to individual functions (shortcut keys)
- 4-ways navigation key
- Separate rotary switches for call groups and audio volume
- Call protocol: missed / answered calls, dialed numbers
- Flexible dialing (e.g. direct dialing, redialing, dialing lists etc.)
- Special microphone
- Top microphone for semi-duplex calls
- Bottom microphone for duplex conversations
- Adjustable display brightness & screensaver
- Many international languages are already available, installation of several optional languages on radio
- Positioning according to ETSI LIP or NMEA protocol
- Completely integrated GPS/GLONASS/Beidou receiver
- Completely programmable position updating
- Display of direction and position of the other call parties
- Transmission of the position data on emergency call
- Integrated BT
- Wireless BT connection to different audio and PTT devices
- Automatic search and detection of compatible BT devices
- PEI interface
- Clock synchronization via GPS/SAT, radio network or local time
- Energy saving mode
- Automatic cell re-selection without call interruption (handover)
- Programming several selectable network identifications (TMO, DMO)
- Programming several selectable PSTN/PABX gateways
- Customizable alarm tones
- Radio User Assignment (RUA)
- Over The Air Interface (OTAP)
- Data /message services
- Short data service (SDS) – types 1, 2, 3, 4 and TL
- Multiple SDS: Long SDS and Flash SDS
- Status message/text message
- Notification of new messages during a call
- Packet Data service (packet data, single-slot, multi-slot)
- Java™ platform MIDP 2.0, WAP
- Operating mode
